Product Information
High-Speed Mixers are produced for effectively mixing and crushing medium and high viscosity liquid groups (Water, Solvent, Printing Inks, Construction Chemicals, Composite materials, Food, Pharmaceuticals, and derivatives.).
- High-Quality Material Selection
- Strong chassis group
- High efficiency
- Floor Installation
- Use of mobile mixing vessels
- Manufacture of medium and high viscosity products
- Machine production -30 lt to – 2000 lt capacity
- Motor power -1.5 kW to -90 kW
- Stepless speed adjustment with Speed Control System
- PLC Control system
- Every part that comes into contact with the product is selected as AISI 304, AISI 316.
Optional Features
- Movable or stationary Vacuum system
- Movable or Fixed cover system
- Vessel Scrapping System
- ATEX Zone 1, EEX Diib, T4, Ex-proof Protective System applications
- Loadcell-Weighing Group
- Temperature Control (Thermocouple)
- YILDIZ Premium Package
| Modal | YMM-100 | YMM-500 | YMM-1000 | YMM-1250 | YMM-1500 | YMM-2000 |
|---|---|---|---|---|---|---|
| Main Engine Power (kW) | 4-7 | 22-30 | 30-37 | 45-55 | 55-75 | 75-90 |
| Rotation Speed (min-1) | 100-1500 | 100-1500 | 100-1400 | 100-1400 | 100-1250 | 100-1250 |
| Batch Size (kg) | 100 kg | 550 kg | 1.050 kg | 1.300 kg | 1.550 kg | 2.050 kg |
| Useable Volume (L) | 80 L | 450 L | 850 L | 1100 L | 1350 L | 1750 L |
